Computer diagnostics of the petrol engine M30B35 on BMW E32

M30B35 ECU identification dаta: coding code c05e, Bosch hardware 0261200150 / software 1267355566, BMW hardware 1720981 / software 013

ECU Identification



M30B35 with lambda-controlled mixture adaptation, Normal version with manual transmission



  • Coding code: c05e
  • Bosch hardware number: 0261200150
  • Bosch software number: 1267355566
  • BMW hardware number: 1720981
  • BMW software number: 013
  • Manufacturing code: 841

Stored Fault Codes



No faults stored!





M30B35 ECU diagnostics: no fault codes stored

Live Data



 3   Fuel pump relay: activated



 5   Fuel tank ventilation valve: not activated



 10   Lambda mixture control: active



 40   Compressor: OFF



 41   Air conditioning: OFF



 42   Drive position P/N: active



 51   Ignition timing intervention: OFF



 52   Neutral position switch signal: activated



 53   Full load switch: not activated



 56   Semi-sequential fuel injection: not activated





M30B35 ECU relay and system statuses: fuel pump, lambda control, A/C, P/N position, injection





 1   Ignition advance angle: 8° BTDC



 6   Engine speed: 800 RPM



 7   Air flow meter reading: 0.221 V



 29   Vehicle speed: 0 km/h



 32   Injection duration: 2.94 ms



 37   ECU supply voltage: 14.17 V



 43   Lambda sensor voltage: 0.179 V



 44   Intake air temperature: 16 °C



 45   Engine temperature: 67 °C



 77   Load signal tL: 2.35 ms





M30B35 ECU measured parameters: RPM 800, ignition timing 8°, injection 2.94 ms, engine temp 67°C, lambda sensor voltage
